Double Layer Electronic 60Hz Portable Pallet Scale

Minimum Order Quantity : 1 Price : Online consultation
Packaging Details : Carton Delivery Time : one week
Payment Terms : T/T Supply Ability : 100000+pc+one week
Place of Origin: CHINA Brand Name: CONHON
Model Number: CHPSS

Detail Information

Product Name: Floor Weighing Scale Range: 300kg,500kg,600kg,1000kg,1500kg,2000kg,3000kg,5000kg
Material: Stainless Steel Structure: Double
Accuracy Class:: III Working Temperature: -10 ℃ ~ + 40 ℃
High Light:

60Hz heavy duty floor scales


60Hz floor scale for pallets


60Hz portable platform scale

Product Description

CHPSS-3T Floor Weighing Scale Double stainless steel electronic platform scale Double stainless steel floor scale

The reliable and hard quality of the double-layer stainless steel electronic platform scale is derived from unparalleled high-quality steel, which can cope with various complex and harsh industrial occasions. All components have undergone rigorous manufacturing and inspection before leaving the factory to ensure that each component is of consistently high quality, thereby ensuring stable and reliable measurement accuracy and measurement repeatability. This series of electronic platform scales can be used for weighing in a variety of occasions, and are widely used in logistics centers, chemical, pharmaceutical and other industrial occasions. This series of reasonable structural design, high rigidity, high strength and longer life. This series of electronic platform scales include various specifications, various capacities and various options to meet different application needs.

Double stainless steel platform scale technical parameters:

Accuracy class: III

Stainless steel meter: LED or LCD with backlight display

Working temperature: -15 ℃ ~ + 50 ℃

Power supply: AC 110 ~ 220V 50 ~ 60Hz or DC4 ~ 6V 4Ah

Structural features of double-layer stainless steel electronic platform scale:

Low countertop with frame structure, new design, increased rigidity, enhanced strength and extended life

Material: 304 stainless steel, double-layer with frame (suitable for pit-type installation)

Stainless steel surface: polished, brushed

Sensors: Four all stainless steel sealed sensors, protection class IP68

Tumbler feet, good self-resetting

Junction box: All stainless steel housing, protection grade is IP68, greatly reducing data drift caused by humidity

Product features:

Waterproof, anticorrosive, dustproof, anti-interference

Zeroing, tare, accumulation, weighing, counting, checkweighing, sorting

Printing, communication interface RS232 / 485 (optional)

4 ~ 20mA analog output (optional)

Relay output, switching value control (optional)


Double stainless steel platform scale:

Configuration The standard configuration Optional
Scale body 304 stainless steel with frame structure Stainless steel
lode cell stainless steel explosion-proof
Junction Box Stainless steel explosion-proof
indicator XK3190-A12ESS Print / Explosion / Counter / Large screen
annex / Leading slope / instrument column / moving mechanism



Double stainless steel platform scale product specifications:

product name Double stainless steel platform scale
Product number CHPSS
Weighing platform height 10cm
Table size



Note: Any non-standard size can be customized according to your requirements

Maximum weighing 600kg 1000kg 2,000kg 3,000kg 5000kg
Accuracy 0.2kg 0.5kg 0.5kg 0.5kg


We specialize in the development of industrial scales. CONHON has mature weighing design and production experience, and has professional weighing and research personnel to provide high-quality non-standard weighing equipment design services and comprehensive weighing control system solutions. Make your company's weighing application double the number of performances on the basis of lower operating costs, increase production efficiency, and maximize profits. Welcome to start your relaxing and enjoyable app journey!
