| Minimum Order Quantity : | 100 | Price : | ￥800-10000/pcs |
|---|---|---|---|
| Delivery Time : | 4-6week | Payment Terms : | T/T |
| Supply Ability : | 99999+pc+1m |
| Place of Origin: | CHINA | Brand Name: | CONHON |
|---|---|---|---|
| Certification: | CE | Model Number: | YBH-2T |
|
Detail Information |
|||
| Range: | 1，1.5，2，2.5t | Material: | Aluminum Alloy |
|---|---|---|---|
| Communication: | RS232/485 | Rated Output: | Accuracy Level |
| Safe Temp. Range: | -10ºC To + 70ºC | Temp. Compensated: | -10ºC To + 40ºC |
| Highlight: | 5t rs232 load cell,RS232 miniature compression load cell,RS485 miniature compression load cell |
||
Product Description
● Miniature sensors
● High-quality stainless steel
● Easy and fast installation
● High precision mini
● High stability
● Suitable for medicine, etc.
|
Rated Output
|
额定输出
|
1.5mV/V ±1%
|
|
Zero Balance
|
零点平衡
|
±3% of rated output
|
|
Creep after 30 minutes
|
蠕变
|
±0.5% of rated output
|
|
Nonlinearity
|
非线性
|
±0.5% of rated output
|
|
Hysteresis
|
滞后
|
±0.5% of rated output
|
|
Repeatability
|
重复性
|
±0.5% of rated output
|
|
Temp. effect on output
|
灵敏度温漂
|
≤0.002% of applied output/ºC
|
|
Temp. effect on zero
|
零点温漂
|
≤0.002% of rated output/ºC
|
|
Safe Temp. Range
|
可用温度范围
|
-10ºC to + 70ºC
|
|
Temp. Compensated
|
温度补偿范围
|
-10ºC to + 40ºC
|
|
Safe Overload
|
安全载荷
|
150%
|
|
Input Impedance
|
输入阻抗
|
387 ohm ± 20 ohm
|
|
Output Impedance
|
输出阻抗
|
350 ohm ± 5 ohm
|
|
Insulation Resistance
|
绝缘阻抗
|
≥5000 M ohm (50V DC)
|
|
Rated Excitation
|
推荐激励电压
|
10V DC/AC
|
|
Maximum Excitation
|
最大激励电压
|
15V DC/AC
|
|
Cable Length
|
导线长度
|
1.5m
|
|
Cable Color Code
|
导线颜色
|
Red(+E) Black(-E) Green(+S) White(-S)
|
